Bosch
GSB 16 RE Impact Drill
Compact power – The most compact and powerful impact drill in its class, Robust and powerful 701 W motor for tough applications
Technical data
| Additional data | |
|---|---|
| Rated input power | 701 W |
| Weight | 1.9 kg |
| Chuck capacity, min./max. | 1.5 – 13 mm |
| No-load speed, 1st gear | 0 – 3,000 rpm |
| Power output | 351 W |
| Drill spindle connecting thread | 1/2" – 20 UNF |
| Tool dimensions (width) | 69 mm |
| Tool dimensions (length) | 292 mm |
| Tool dimensions (height) | 194 mm |
| Impact rate at no-load speed | 0 – 48,000 bpm |
| Drilling range | |
|---|---|
| Drilling diameter in masonry | 18 mm |
| Drilling diameter in concrete | 16 mm |
| Drilling diameter in wood | 30 mm |
| Drilling diameter in steel | 12 mm |
| Total vibration values (Drilling in metal) | |
|---|---|
| Vibration emission value ah | 2.7 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Impact drilling in concrete) | |
|---|---|
| Vibration emission value ah | 23 m/s² |
| Uncertainty K | 3.5 m/s² |
| Total vibration values (Screwdriving) | |
|---|---|
| Vibration emission value ah | 2.5 m/s² |
| Uncertainty K | 1.5 m/s² |
