Bosch
GBH 8-45 DV Rotary Hammer with SDS max
Powerful 1500 watt at low vibrations, Three-way Vibration Control System, Turbo Power Function
Technical data
| Additional data | |
|---|---|
| Rated input power | 1,500 W |
| Impact energy | 12.5 J |
| Impact rate at rated speed | 1,380 – 2,760 bpm |
| Rated speed | 150 – 305 rpm |
| Weight | 8.9 kg |
| Tool dimensions (width) | 116 mm |
| Tool dimensions (length) | 540 mm |
| Tool dimensions (height) | 310 mm |
| Tool holder | SDS max |
| Drilling range | |
|---|---|
| Drilling dia. concrete, hammer drill bits | 12 – 45 mm |
| Opt. appl. range concrete, hammer drill bits | 20 – 40 mm |
| Drilling dia. concrete, breakthrough drill bits | 80 mm |
| Drilling diameter in concrete with core cutters | 125 mm |
| Total vibration values (Hammer drilling in concrete) | |
|---|---|
| Vibration emission value ah | 8 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Chiselling) | |
|---|---|
| Vibration emission value ah | 7 m/s² |
| Uncertainty K | 1.5 m/s² |
