Description

High quality cast iron mechanics vices capable of achieving up to 4000 Kg of clamping force for general metal working applications

Specification

• Body and sliding jaw are manufactured from high quality grey cast iron with hardened steel replaceable jaw plates.
• Main screw and tommy bar are made from high quality steel.

Features and Benefits

• Hardened steel jaw plates and cast iron body can achieve up to 4000 Kgf clamping force
• Strong and durable with excellent shock adsorbing properties
• Tommy bar will bend before the vice becomes over stressed
• Sliding jaw is precision milled to a high tolerance for a fast smooth operation
• Base has fixing holes for bench mounting
• Fibre grips, swivel bases and spare jaw plates are available as accessories

Sizes and Benefits

• Part no	Jaw Width	Throat Depth	Jaw Opening	Clamping Force Kg f (Max)	Net Weight (KG)
  EMV-1	75mm (3")	48mm	82mm	1500 Kgf	4.8 Kg
  EMV-3	100mm (4")	63mm	109mm	2000 Kgf	9.3 Kg
  EMV-5	125mm (5")	73mm	136mm	2500 Kgf	15.8 Kg
  EMV-6	150mm (6")	86mm	168mm	3000 Kgf	24.2 Kg
  EMV-8	200mm (8")	103mm	208mm	4000 Kgf	38.1 Kg
